Sapphire Products >> Stock Items >> Aspheric Sapphire Dome SD10805A

Aspheric Sapphire Dome - 100mm Caliber x 80mm Dome Height
sapphire-windows-sapphire-lens

sapphire dome
    Specifications of Aspheric Sapphire Dome SD10805A
  • Code: SD10805A
  • Material: Sapphire crystal
  • Caliber: 100mm ± 0.1
  • Wall thickness: 5mm ± 0.1
  • Dome height: 80mm ± 0.1
  • Surface Quality S/D: 80/50
  • Surface roughness: 2.0
  • C axis deviation: 4°




sapphire-windows-sapphire-lens
Sapphire Domes Features and Applications:
1. High transparent to wavelengths of light between 0.3 μm (UV) and 5 μm (IR)
2. Extremely hard and scratch resistance
3. Extremely high melting temperature (2030°C)
4. Excellent thermal conductivity and heat resistance
5. Exceptional chemical stability and corrosion resistance
6. Sapphire domes are ideal for the applications of extreme conditions, such as aerospace or deep sea applications.
sapphire-windows-sapphire-lens
Custom Specifications of Sapphire Domes:
Caliber (D): Ø20mm ~ Ø400mm
Wall thickness (T): ≥ 1mm
Dome height (H): ≤ R2
Dimension Tolerance : 0.01mm
Facial contour N: ≥ λ
Irregularity △N: ≥ 1/4
Surface quality: 40/20
Surface roughness: < 0.5
Center deviation: ≤ 1′
Custom shape: Hemisphere Sapphire Dome, Hyper hemisphere sapphire dome, Aspheric sapphire dome, Kerf sapphire dome
sapphire-windows-sapphire-lens
Sapphire Domes in Stock
Hemisphere sapphire dome SD10504H 100mm Caliber x 50mm Dome Height
Hyper Hemisphere sapphire dome SD10605H 100mm Caliber x 60mm Dome Height
Kerf sapphire dome SD12606K 120mm Caliber x 60mm Dome Height
